Alcatel-Lucent Enterprise OmniSwitch 2360 Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Stainless steel
- 24 and 48 Gigabit Ethernet data or PoE+ ports with line-rate performance
- Gigabit Ethernet SFP uplink ports or 10 Gigabit Ethernet SFP+ uplink ports (X models)
- 10 GigE virtual chassis bandwidth up to 4 units (stacking) or 216 ports
- Perpetual and fast PoE+ support across all PoE models
- Compact fan-less models for co-location work environments
The Alcatel-Lucent OmniSwitch 2360 Stackable Gigabit Ethernet LAN switch family delivers value and is optimised for small and medium businesses (SMB), as well as branch/campus workgroup solutions.
The enterprise-grade OmniSwitch 2360 family delivers high- performance, availability, security, and scalability. This family of switches provides a solid foundation to support business communications, applications, users and devices. Unified network management is employed for a consistent wired and wireless experience. The OmniSwitch 2360 family is embedded with the latest technology innovations and offers maximum investment protection.
| Management features |
| System event log |
Yes |
| Web-based management |
Yes |
| Cloud-managed |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2+ |
| Switch type |
Managed |
| Ports & interfaces |
| Fiber uplink ports quantity |
2 |
| SFP+ module slots quantity |
2 |
| SFP module slots quantity |
4 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
48 |
| Network |
| VLAN support |
Yes |
| Link aggregation |
Yes |
| Auto-sensing |
Yes |
| Flow control support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Auto-negotiation |
Yes |
| Spanning tree protocol |
Yes |
| IP routing |
Yes |
| Port mirroring |
Yes |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Data transmission |
| Jumbo frames |
12000 |
| Jumbo frames support |
Yes |
| Static route |
Yes |
| Forwarding rate |
107.1 Mpps |
| Switching capacity |
216 Gbit/s |
| Security |
| SSH/SSL support |
Yes |
| IGMP snooping |
Yes |
| Access Control List (ACL) |
Yes |
| DHCP features |
DHCP Option 82, DHCP client, DHCP relay, DHCP server |
| Multicast features |
| Multicast support |
Yes |
| Design |
| Number of fans |
1 fan(s) |
| Product colour |
Stainless steel |
| Stackable |
Yes |
| Rack mounting |
Yes |
| Performance |
| Mean time between failures (MTBF) |
625000 h |
| Noise level |
40 dB |
| Flash memory |
512 MB |
| Internal memory |
1024 MB |
| Processor frequency |
1000 MHz |
| Built-in processor |
Yes |
| Power |
| Power supply included |
Yes |
| Power source |
AC |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
370 W |
| Power over Ethernet plus (PoE+) ports quantity |
48 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
| Operating relative humidity (H-H) |
5 – 95% |
| Storage temperature (T-T) |
-20 – 60 °C |
| Operating temperature (T-T) |
0 – 45 °C |
| Weight & dimensions |
| Weight |
4.2 kg |
| Height |
44 mm |
| Depth |
300 mm |
| Width |
440 mm |
