AMD 100-505959 graphics card Radeon RX Vega 64 16 GB High Bandwidth Memory 2 (HBM2)
- Based on cutting-edge “VEGA” GRAPHICS ARCHITECTURE built to handle big data sets and diverse compute workloads
- 64 nCU COMPUTE UNITS to accelerate demanding workloads
- Up to 12.3 TFLOPS of peak FP32 compute performance to speed up compute intensive machine intelligence
- Up to 24.6 TFLOPS of FP16 peak compute performance for deep learning training applications
- State-of-the-art memory technology: 16GB of HBM2 MEMORY with ECC2 and HIGH BANDWIDTH CACHE CONTROLLER (HBCC)
- Passively cooled, full-height, dual-slot, 300W TDP board power – designed to fit in most standard server designs
- MxGPU for Virtualized Compute Workloads – drive greater utilization and capacity in the data center
- Advanced Remote Manageability Capabilities, for simplified GPU monitoring in large scale systems
The Ultimate Solution for Your Computing Needs
Machine Intelligence and Deep Learning Neural Network Training
– High performance FP16 and FP32 compute
– Open software ROCm platform for HPC-class rack scale
– Optimized MIOpen deep learning framework libraries
– Large BAR support for mGPU peer to peer
– Superior compute density and performance per node when combining AMD EPYC™ server processor and Radeon Instinct™ accelerators
HPC Heterogeneous Compute
– Outstanding compute density and performance per node
– Open software ROCm platform for HPC class rack scale
– Open source Linux drivers, HCC compiler, tools and libraries from the metal forward
– Open industry standard support of multiple architectures and industry standard interconnect technologies
Processor |
Stream processors |
4096 |
Graphics processor |
Radeon RX Vega 64 |
Graphics processor family |
AMD |
Memory |
Bandwidth |
484 GHz |
Memory bus |
2048 bit |
Graphics card memory type |
High Bandwidth Memory 2 (HBM2) |
Discrete graphics card memory |
16 GB |
Ports & interfaces |
Interface type |
PCI Express x16 3.0 |
Performance |
OpenCL version |
2.0 |
OpenGL version |
4.6 |
DirectX version |
12.0 |
Design |
Product colour |
Black |
Cooling type |
Passive |
Power |
Supplementary power connectors |
2x 8-pin |
Power consumption (typical) |
300 W |
Weight & dimensions |
Length |
267 mm |
Logistics data |
Harmonized System (HS) code |
84733020 |
