DELL PowerEdge R6515 server 480 GB Rack (1U) AMD EPYC 7282 2.8 GHz 16 GB DDR4-SDRAM 550 W
- No OS
- AMD EPYC 7282 (64MB Cache, 2.8GHz)
- 16GB DDR4-SDRAM (1 x 16) Dual Rank & 480GB SSD
- iDRAC9 Enterprise 15G
Dual-socket performance in a single-socket 1U rack design
The Dell EMC PowerEdge R6515 is a single-socket 1U server designed to handle workloads like virtualization, HCI and OpenStack Ready Architecture.
| Processor |
| Number of processors installed |
1 |
| Processor cache |
64 MB |
| Processor boost frequency |
3.2 GHz |
| Processor frequency |
2.8 GHz |
| Processor model |
7282 |
| Processor family |
AMD EPYC |
| Processor manufacturer |
AMD |
| Memory |
| Maximum internal memory |
128 GB |
| Memory data transfer rate |
3200 MT/s |
| Memory clock speed |
3200 MHz |
| Memory layout (slots x size) |
1 x 16 GB |
| Memory ranking |
2 |
| Buffered memory type |
Registered (buffered) |
| Internal memory type |
DDR4-SDRAM |
| Internal memory |
16 GB |
| Storage |
| Drive writes per day (DWPD) |
3 |
| Optical drive type |
No |
| Hot-Plug support |
Yes |
| Supported RAID controllers |
PERC H730P |
| Number of SSDs supported |
8 |
| SSD size |
2.5″ |
| Supported SSD sizes |
2.5″ |
| SSD interface |
SATA |
| SSD capacity |
480 GB |
| Number of SSDs installed |
1 |
| Supported HDD sizes |
2.5″ |
| Number of HDDs supported |
8 |
| Total storage capacity |
480 GB |
| Graphics |
| On-board graphics card model |
Not available |
| On-board graphics card |
No |
| Network |
| LAN controller |
Broadcom 5720 |
| Ethernet LAN |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet interface type |
Gigabit Ethernet |
| Ports & interfaces |
| Power cables quantity |
1 |
| VGA (D-Sub) ports quantity |
2 |
| Serial ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 2.0 ports quantity |
1 |
| Expansion slots |
| PCI Express x16 slots |
2 |
| Design |
| Bezel |
Yes |
| Product colour |
Black |
| Chassis type |
Rack (1U) |
| Performance |
| Remote administration |
iDRAC9 Enterprise 15G |
| Software |
| Compatible operating systems |
– Canonical Ubuntu Server LTS- Citrix Hypervisor- Microsoft Windows Server with Hyper-V- Red Hat Enterprise Linux- SUSE Linux Enterprise Server- VMware ESXi |
| Operating system installed |
No |
| Power |
| Power cable current |
10 A |
| Power cable connector 2 |
C14 coupler |
| Power cable connector 1 |
C13 coupler |
| Power cable length |
2 m |
| Number of main power supplies |
1 |
| Number of redundant power supplies supported |
2 |
| Power supply |
550 W |
| Redundant power supply (RPS) support |
Yes |
| Operational conditions |
| Non-operating altitude |
0 – 12000 m |
| Operating altitude |
0 – 3048 m |
| Storage relative humidity (H-H) |
5 – 95% |
| Operating relative humidity (H-H) |
8 – 80% |
| Storage temperature (T-T) |
-40 – 65 °C |
| Operating temperature (T-T) |
10 – 35 °C |
| General |
| Product family |
PowerEdge |
| Logistics data |
| Harmonized System (HS) code |
84714100 |
| Weight & dimensions |
| Height |
42.8 mm |
| Width |
482 mm |
| Other features |
| Data transfer rate |
6 Gbit/s |
| Bytes per sector |
512 |
