DrayTek ANT-1205 network antenna Omni-directional antenna RP-SMA 5 dBi
- High-Gain Dual-Band Aerials
- Set of 2 Antennas
- Available in white or black
- Can improve range and coverage of wireless signal
- Suitable for all DrayTek routers & access Points
- Suitable for 802.11ac & 802.11ax (Wi-Fi 6)
- Frequency Range : 2400-2500Mhz & 5150-5850Mhz
- 4.5dBi Gain at 5.8Ghz
- 5dBi Gain at 2.4Ghz
- Connector: RP-SMA
- Suitable for indoor use only
- Optional magnetic/extension base (ANT-BAS1)
Draytek ANT-1205B 5dB WiFi Aerial Black
Performance |
Vertical beam width (5 GHz) |
25° |
Vertical beam width (2.4 GHz) |
30° |
Horizontal beam width |
360° |
Impedance |
50 Ω |
Antenna gain (2.4 GHz) |
2 dBi |
Antenna gain (5 GHz) |
4.5 dBi |
Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Frequency band |
2.4 – 5 GHz |
Antenna gain level (max) |
5 dBi |
Features |
Power handling |
1 W |
Product colour |
Black |
Polarization |
Linear polarization |
Antenna connector type |
RP-SMA |
Antenna type |
Omni-directional antenna |
Weight & dimensions |
Diameter |
1.3 cm |
Height |
198 mm |
Packaging content |
Quantity per pack |
2 pc(s) |
