Epson LQ-590IIN dot matrix printer 550 cps
- 550 cps Black
- 55 dB
- Buffer size: 128 KB
- Standard interfaces: Ethernet, USB 2.0
- Print head: 24-pin
- Mean time between failures (MTBF): 25000 h
The LQ-590IIN is a high-volume dot matrix printer designed for fast and reliable printing. Upgrade your existing dot matrix printers to our latest model, which is now Energy Star compliant, and delivers built-in network capability with an incredibly low TCO.
Fast print speed
The LQ-590IIN offers an improved USD (ultra speed draft) speed of 550 characters per second at 10 characters per inch, making a real difference to high-volume print runs such as stock reports and large batches of invoices or freight documents.
Increased reliability
Epson’s dot matrix technology is already mature and very reliable. Building on this, the new printer improves the mean time between failure by 25% to 25,000 power-on hours, ideal for challenging conditions or where regular maintenance is not practical.
Same consumables
This printer uses the same ribbons as existing models, so you can upgrade your hardware and continue to use your current ribbon supplies.
Network capability
This is a network model which supports both serial and Ethernet connections for enhanced connectivity.
| Printing | |
|---|---|
| Character sets | ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8 |
| Built-in barcodes | Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E |
| Maximum print speed | 550 cps |
| Maximum printing width (columns) | 80 |
| Paper handling | |
|---|---|
| Continuous paper thickness range | 0.065 – 0.49 mm |
| Features | |
|---|---|
| Country of origin | Indonesia |
| Sound pressure level (printing) | 55 dB |
| Buffer size | 128 KB |
| Product colour | Black |
| Ports & interfaces | |
|---|---|
| Standard interfaces | Ethernet, USB 2.0 |
| Endurance | |
|---|---|
| Mean time between failures (MTBF) | 25000 h |
| Print head | 24-pin |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 – 80% |
| Operating temperature (T-T) | 5 – 35 °C |
| Weight & dimensions | |
|---|---|
| Weight | 7.2 kg |
| Height | 177 mm |
| Depth | 375 mm |
| Width | 437 mm |
| Packaging data | |
|---|---|
| Package weight | 9.28 kg |
| Package height | 80 mm |
| Package depth | 340 mm |
| Package width | 40 mm |
| Quantity per pack | 1 pc(s) |
| Technical details | |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Logistics data | |
|---|---|
| Products per pallet | 14 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross height | 7.43 m |
| Products per pallet layer | 2 pc(s) |
| Pallet gross length | 120 cm |
| Products per pallet layer (UK) | 4 pc(s) |
| Pallet width (UK) | 100 cm |
| Products per pallet (UK) | 28 pc(s) |
| Pallet height (UK) | 7.43 m |
| Pallet length (UK) | 120 cm |
