Epson WorkForce DS-30000 Sheet-fed scanner 600 x 600 DPI A3 Black, White
- Space saving: Compact design without compromise on engineering quality
- Fast performance: Up to 70ppm/140ipm scanning at 200 or 300dpi colour
- Flexible scanning: Scan passports and bound media up to 6mm in thickness
- Control and security: Advanced paper handing with paper-protection sensors
- High capacity: Heavy duty 120-sheet document feeder (ADF)
The WorkForce DS-30000 is Epson’s first compact A3 desktop scanner. Designed for busy office environments, it features a high-capacity feeder, wide media scanning capabilities and a touchscreen front panel that puts users in control to scan up to 30,000 pages per day
Thanks to Epson’s new Complex Production Architecture, the DS-30000 has been engineered to the highest standards to meet the demands of busy departments.
High in capacity and with a robust design, the Automatic Document Feeder (ADF) has the ability to scan the widest range of media in its class¹. Scan passports2, passbooks, ID cards and large-format documents.
Simplify scanning tasks, putting users in control with a 2.7″ backlit touchscreen that can display pre-defined scan jobs and highlights machine cleaning and maintenance requirements with easy-to-follow, step-by-step instructions.
The inbuilt advanced paper-protection sensors also prevent documents from being damaged and ultra-sonic sensors ensure all documents are scanned, maintaining data integrity.
The DS-30000 comes with Document Capture Pro 3.0 software with inbuilt OCR functionality, supporting crisp, clear images. A wide range of drivers, including TWAIN, ISIS, WIA, SANE, and ICA allow for easy integration into most document management systems.
For added flexibility and convenience, the optional A4 (DS-5500) and A3 (DS-50000) flatbed scanners enable scanning
| Scanning | |
|---|---|
| ADF scan speed (b/w, A4) | 70 ppm |
| Output colour depth | 8 bit |
| Input colour depth | 10 bit |
| Duplex scanning | Yes |
| Colour scanning | Yes |
| Optical scanning resolution | 600 x 600 DPI |
| Maximum scan size | 304.8 x 5588 mm |
| Design | |
|---|---|
| Display diagonal | 6.86 cm (2.7″) |
| Display | LCD |
| Product colour | Black, White |
| Built-in display | Yes |
| Scanner type | Sheet-fed scanner |
| Performance | |
|---|---|
| Sound pressure level (max) | 51 dB |
| Daily duty cycle (max) | 30000 pages |
| Sensor type | CIS |
| Input capacity | |
|---|---|
| Auto document feeder (ADF) input capacity | 120 sheets |
| Paper handling | |
|---|---|
| Maximum ISO A-series paper size | A3 |
| Ports & interfaces | |
|---|---|
| Standard interfaces | USB 3.2 Gen 1 (3.1 Gen 1) |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB port | Yes |
| Power | |
|---|---|
| Input voltage | 100 – 240 V |
| Sleep mode | Yes |
| Power consumption (off) | 0.1 W |
| Power consumption (standby) | 9 W |
| Power supply type | AC |
| Power consumption (typical) | 17 W |
| Weight & dimensions | |
|---|---|
| Weight | 5.8 kg |
| Height | 219 mm |
| Depth | 208 mm |
| Width | 371 mm |
| General | |
|---|---|
| Product family | WorkForce |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 15 – 85% |
| Operating relative humidity (H-H) | 15 – 80% |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84716070 |
