Evo Labs BR600-12BL power supply unit 600 W 20+4 pin ATX ATX Black
- New Version PSU ATX 2.2/2.3
- 120mm Black Silent Cooling Fan
- Silent operation with improved ventilation
- PFC: Power Factor Control
- ATX 12V compliant for most CPUs and mainboards
- 3 x SATA Connectors
- Stable & Reliable
The NEW Evo Labs E-600BL ATX 600W power supply with a 120mm black fan provides improved airflow and ventilation for you PC system.
| Power | |
|---|---|
| Input current | 10 A |
| AC input frequency | 50 – 60 Hz |
| AC input voltage | 230 V |
| Total power | 600 W |
| Ports & interfaces | |
|---|---|
| Cabling type | Non-Modular |
| Floppy disk drive connector | Yes |
| CPU P4 connector (4-pin) | 1 |
| PCI Express power connectors (6-pin) | 1 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Number of SATA power connectors | 3 |
| Motherboard power connector | 20+4 pin ATX |
| Performance | |
|---|---|
| Mean time between failures (MTBF) | 100000 h |
| Noise level | 17 dB |
| Silent mode | Yes |
| ATX version | 2.3 |
| Power supply unit (PSU) form factor | ATX |
| Purpose | PC |
| Design | |
|---|---|
| Fan diameter | 12 cm |
| Cooling type | Active |
| Product colour | Black |
| Certificates | |
|---|---|
| Certification | CE, ROHS |
| Weight & dimensions | |
|---|---|
| Weight | 1.3 kg |
| Height | 85 mm |
| Depth | 140 mm |
| Width | 150 mm |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84733020 |
