GIGABYTE AORUS EZ CHAIN FAN 120 (3-Pack) Motherboard 12 cm Black 3 pc(s)
- Fan EZ-Chain: DIY-friendly fan design with slide-in interlocking mechanism and DAISY-CHAIN
- New fan blade design increases both airflow and pressure, while reducing noise
- The ARGB fan lighting can be synchronized with other devices
- Universal design for fan RPM control, compatible with all motherboard brands
- Need only one cable to connect multiple AORUS EZ-CHAIN ARGB fans
- Big airflow reduces system temperatures by expelling waste heat Quiet, low-noise fans
- Supports synchronization with AORUS WATERFORCE X II series & AORUS WATERFORCE II series liquid cooling RGB lighting
DIY-friendly Innovations
Say goodbye to time wasted on wiring connections
Fan EZ-Chain incorporates a slide-in interlocking mechanism along with a DAISY-CHAIN setup, enabling the transmission of power and signals between fans, thereby saving a significant amount of time on wiring connections.
New Fan Blade Design
The new fan blade design has achieved a simultaneous increase in both airflow and pressure, along with a reduction in noise.
BUILD BETTER. BUILD SMARTER.
With GCC (GIGABYTE Control Center), each device uses the same universal connector, plugging directly into the next to create a simple chain of devices.
| Performance | |
|---|---|
| Fan’s mean time to failure (MTTF) | 40000 h |
| Fan speed (max) | 2000 RPM |
| Fan speed (min) | 600 RPM |
| Quantity per pack | 3 pc(s) |
| Fan noise level (max) | 29 dB |
| Fan noise level (min) | 8.2 dB |
| Bearing type | Hydro Dynamic Bearing (HDB) |
| Maximum air pressure | 2.75 mmH2O |
| Maximum airflow | 60 cfm |
| Supported processor sockets | Not supported |
| Fan diameter | 12 cm |
| Type | Fan |
| Suitable location | Motherboard |
| Design | |
|---|---|
| Illumination colour | Multi |
| Illumination LED | Yes |
| Number of fan blades | 9 |
| Number of fans | 3 fan(s) |
| Product colour | Black |
| Weight & dimensions | |
|---|---|
| Height | 25 mm |
| Depth | 120 mm |
| Width | 120 mm |
| Technical details | |
|---|---|
| Warranty period | 2 year(s) |
- AORUS EZ CHAIN FAN
