Intel Celeron G1820 processor 2.7 GHz 2 MB Smart Cache
- Intel® Celeron® G G1820 2.7 GHz
- 2 MB Smart Cache LGA 1150 (Socket H3)
- Processor cores: 2 22 nm 64-bit 53 W
- Maximum internal memory supported by processor: 32 GB DDR3-SDRAM, DDR3L-SDRAM
- On-board graphics card Intel® HD Graphics
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.
Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software. Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.
Processor | |
---|---|
Processor ARK ID | 78955 |
Processor codename | Haswell |
Memory bandwidth supported by processor (max) | 21.3 GB/s |
Bus type | DMI |
Stepping | C0 |
Thermal Design Power (TDP) | 53 W |
Processor cache type | Smart Cache |
Processor cache | 2 MB |
Processor operating modes | 64-bit |
System bus rate | 5 GT/s |
Processor threads | 2 |
Component for | PC |
Cooler included | No |
Box | No |
Processor lithography | 22 nm |
Processor socket | LGA 1150 (Socket H3) |
Processor cores | 2 |
Processor base frequency | 2.7 GHz |
Processor model | G1820 |
Processor family | Intel® Celeron® G |
Processor manufacturer | Intel |
Memory | |
---|---|
ECC | Yes |
Memory channels | Dual-channel |
Memory clock speeds supported by processor | 1333 MHz |
Memory types supported by processor | DDR3-SDRAM, DDR3L-SDRAM |
Maximum internal memory supported by processor | 32 GB |
Graphics | |
---|---|
On-board graphics card refresh rate at maximum resolution (VGA) | 60 Hz |
On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) | 60 Hz |
On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
On-board graphics card maximum resolution (DisplayPort) | 2560 x 1600 pixels |
On-board graphics card maximum resolution (VGA) | 1920 x 1200 pixels |
On-board graphics card maximum resolution (eDP – Integrated Flat Panel) | 2560 x 1600 pixels |
On-board graphics card maximum resolution (HDMI) | 1920 x 1080 pixels |
On-board graphics card DirectX version | 11.1/12 |
On-board graphics card OpenGL version | 4.3 |
Number of displays supported (on-board graphics) | 3 |
On-board graphics card dynamic frequency (max) | 1050 MHz |
On-board graphics card base frequency | 350 MHz |
On-board graphics card outputs supported | Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI, VGA (D-Sub) |
Maximum on-board graphics card memory | 1.7 GB |
On-board graphics card model | Intel® HD Graphics |
On-board graphics card | Yes |
Features | |
---|---|
Commodity Classification Automated Tracking System (CCATS) | NA |
Export Control Classification Number (ECCN) | 3A991 |
Scalability | 1S |
Embedded options available | Yes |
Graphics & IMC lithography | 22 nm |
CPU configuration (max) | 1 |
Thermal solution specification | PCG 2013C |
Bandwidth | 5 MB/s |
Supported instruction sets | SSE4.1, SSE4.2 |
PCI Express configurations | 1×16, 2×8, 1×8+2×4 |
PCI Express slots version | 3.0 |
Maximum number of PCI Express lanes | 16 |
Market segment | Desktop |
Execute Disable Bit | Yes |
Idle States | Yes |
Thermal Monitoring Technologies | Yes |
Processor special features | |
---|---|
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Secure Key Technology version | 1.00 |
Intel 64 | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel Stable Image Platform Program (SIPP) version | 0.00 |
Intel Virtualization Technology for Directed I/O (VT-d) | No |
Intel® Secure Key | Yes |
Intel TSX-NI | No |
Intel® Optane™ Memory Ready | No |
Intel Enhanced Halt State | Yes |
Intel® vPro™ Platform Eligibility | No |
Intel TSX-NI version | 0.00 |
Conflict-Free processor | Yes |
Intel Stable Image Platform Program (SIPP) | No |
Intel® Transactional Synchronization Extensions | No |
Intel® Hyper Threading Technology (Intel® HT Technology) | No |
Intel® Turbo Boost Technology | No |
Intel® AES New Instructions (Intel® AES-NI) | No |
Intel Trusted Execution Technology | No |
Intel® Quick Sync Video Technology | Yes |
Intel® Smart Cache | Yes |
Enhanced Intel SpeedStep Technology | Yes |
General | |
---|---|
Product family | Celeron |
Operational conditions | |
---|---|
Tcase | 72 °C |
Logistics data | |
---|---|
Harmonized System (HS) code | 85423119 |
Technical details | |
---|---|
End of servicing updates date | Wednesday, June 30, 2021 |
Servicing status | End of Servicing Lifetime |
Maximum resolution & refresh rate (VGA) | 1920×1200@60Hz |
Number of graphics cores | 10 |
Bus bandwidth | 5 |
Bus type units | GT/s |
Maximum resolution & refresh rate (HDMI) | 1920×1080@60Hz |
Maximum resolution & refresh rate (Integrated Flat Panel) | 2560×1600@60Hz |
Processor brand name | Intel Celeron |
Last change | 63903513 |
Product family | Intel Celeron Processor |
Launch date | Q1’14 |
Status | Launched |
Maximum resolution & refresh rate (DisplayPort) | 2560×1600@60Hz |
Maximum memory | 32 GB |
Bus speed | 5 GT/s |
Processor cache | 2048 KB |
Supported memory types | DDR3-SDRAM, DDR3L-SDRAM |
Product type | Processor |
Maximum graphics card memory | 1.7 GB |
Packaging data | |
---|---|
Package type | Retail box |
Package weight | 338 g |
Package height | 102 mm |
Package depth | 114 mm |
Package width | 81 mm |
Weight & dimensions | |
---|---|
Processor package size | 37.5 x 37.5 mm |
Other features | |
---|---|
Graphics output | eDP/DP/HDMI/DVI/VGA |
Maximum internal memory | 32 GB |
Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
