Intel Killer Wi-Fi 7 BE1750 Internal WLAN / Bluetooth 5800 Mbit/s
- Wireless
- M.2 WLAN / Bluetooth
- 5800 Mbit/s
- Wi-Fi Tri-band (2.4 GHz / 5 GHz / 6 GHz) Bluetooth 5.4
- Internal Component for: PC/Laptop
Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.
| Ports & interfaces |
| Interface |
WLAN / Bluetooth |
| Host interface |
M.2 |
| Connectivity technology |
Wireless |
| Network |
| MU-MIMO |
Yes |
| Bluetooth version |
5.4 |
| Bluetooth |
Yes |
| Security algorithms |
AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3 |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Wi-Fi band |
Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Wi-Fi |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w |
| Maximum data transfer rate |
5800 Mbit/s |
| Design |
| Antenna type |
2×2 |
| Component for |
PC/Laptop |
| Internal |
Yes |
| System requirements |
| Linux operating systems supported |
Yes |
| Windows operating systems supported |
Windows 10, Windows 11 |
| Operational conditions |
| Operating temperature (T-T) |
0 – 80 °C |
| Sustainability |
| Sustainability compliance |
Yes |
| Weight & dimensions |
| Weight |
3.07 g |
| Height |
2.4 mm |
| Depth |
30 mm |
| Width |
22 mm |
| Technical details |
| Compliance certificates |
CB, UL |
| Logistics data |
| Harmonized System (HS) code |
8517620090 |
| Other features |
| Launch date |
Q3’23 |
| Status |
Launched |
| Supported Under vPro |
Yes |
| Ethernet adapter ARK ID |
230084 |
| Export Control Classification Number (ECCN) |
5A992C |
| Commodity Classification Automated Tracking System (CCATS) |
740.17B1 |
