Intel Wi-Fi 6E AX210 Internal WLAN 2400 Mbit/s
- Wireless
- PCI Express WLAN
- 2400 Mbit/s
- Wi-Fi Bluetooth 5.3
- Internal Component for: PC/Laptop
Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.
Ports & interfaces |
Interface |
WLAN |
Host interface |
PCI Express |
Connectivity technology |
Wireless |
Network |
MU-MIMO |
Yes |
Bluetooth version |
5.3 |
Bluetooth |
Yes |
Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
Wi-Fi |
Yes |
Maximum data transfer rate |
2400 Mbit/s |
Design |
Package size |
22 x 30 x 2.4 mm |
Antenna type |
2×2 |
Component for |
PC/Laptop |
Internal |
Yes |
System requirements |
Linux operating systems supported |
Yes |
Windows operating systems supported |
Windows 10 x64 |
Compatible operating systems |
Windows 10, 64-bit*|Linux* |
Operational conditions |
Operating temperature (T-T) |
0 – 80 °C |
Weight & dimensions |
Weight |
2.8 g |
Height |
30 mm |
Depth |
2.4 mm |
Width |
22 mm |
Logistics data |
Harmonized System (HS) code |
85176990 |
Other features |
Product series |
Intel® Wireless Products |
Launch date |
Q4’20 |
Status |
Launched |
Processor family |
Intel Wi-Fi 6E Products |
Supported Under vPro |
Yes |
Compliance |
FIPS, FISMA |
Export Control Classification Number (ECCN) |
5A992CN3 |
Commodity Classification Automated Tracking System (CCATS) |
G165483 |
Maximum operating temperature |
80 °C |
Minimum operating temperature |
0 °C |
