Intel Xeon D-1557 processor 1.5 GHz 18 MB L3
- Intel® Xeon® D D-1557 1.5 GHz
- 18 MB L3 BGA 1667
- Processor cores: 12 14 nm 64-bit 45 W
- Maximum internal memory supported by processor: 128 GB DDR4-SDRAM, DDR3-SDRAM
Extending Intelligence to the Edge
The Intel® Xeon® processor D product family brings advanced intelligence and performance into a dense, low-power system on a chip (SoC).
A New Option for Network, Storage, and IoT Infrastructure
The Intel® Xeon® processor D-1500 product family brings the performance and advanced intelligence of Intel Xeon processors into a dense, low-power system on a chip. With enhanced reliability, availability, and serviceability features; platform storage extensions; and built-in hardware virtualization; the Intel Xeon processor D-1500 product family offers new options for optimizing a variety of workloads and infrastructure for midrange routers, network appliances, security appliances, wireless base stations, embedded midrange Internet of Things (IoT) devices, entry networking, midrange storage area network (SAN) and network attached storage (NAS) appliances, warm cloud storage, and more.
High Performance from Data Center to Network Edge
Built-in Hardware Virtualization
Enables dynamic provisioning of services as communication service providers extend network functions virtualization (NFV) to the network edge.
Intel® Platform Storage Extensions
Enables smarter and more cost-effective storage solutions through integrated technologies that accelerate data movement, help protect data, and simplify data management.
Intel x86 64-bit Software
Support for scalable performance and broad application compatibility.
| Processor | |
|---|---|
| Processor ARK ID | 93364 |
| Processor codename | Broadwell |
| Stepping | Y0 |
| Thermal Design Power (TDP) | 45 W |
| Processor cache type | L3 |
| Processor cache | 18 MB |
| Processor boost frequency | 2.1 GHz |
| Processor operating modes | 64-bit |
| Processor threads | 24 |
| Processor series | Intel Xeon D-1500 |
| Component for | Server/workstation |
| Cooler included | No |
| Box | No |
| Processor lithography | 14 nm |
| Processor socket | BGA 1667 |
| Processor cores | 12 |
| Processor base frequency | 1.5 GHz |
| Processor model | D-1557 |
| Processor family | Intel® Xeon® D |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Dual-channel |
| Memory types supported by processor | DDR4-SDRAM, DDR3-SDRAM |
| Maximum internal memory supported by processor | 128 GB |
| Graphics | |
|---|---|
| On-board graphics card | No |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | G071701++ |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Scalability | 1S |
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Supported instruction sets | AVX 2.0 |
| PCI Express configurations | 1×16, 1×4, 1×8 |
| PCI Express slots version | 2.0, 3.0 |
| Maximum number of PCI Express lanes | 32 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| I/O configuration | |
|---|---|
| UART | Yes |
| General Purpose IO | Yes |
| Integrated LAN | Yes |
| Total number of SATA connectors | 6 |
| USB ports quantity | 8 |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Processor special features | |
|---|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Secure Key | Yes |
| Intel TSX-NI | Yes |
| Intel® OS Guard | Yes |
| Intel Enhanced Halt State | Yes |
| Intel TSX-NI version | 1.00 |
| Conflict-Free processor | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Turbo Boost Technology 2.0 frequency | 2.1 GHz |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| General | |
|---|---|
| Product family | Xeon |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8542310001 |
| Technical details | |
|---|---|
| End of servicing updates date | Saturday, December 31, 2022 |
| Servicing status | End of Servicing Updates |
| Processor brand name | Intel Xeon |
| Last change | 63903513 |
| Product family | Intel Xeon Processor D Family |
| Launch date | Q1’16 |
| Status | Launched |
| Memory speed (max) | 2133 MHz |
| Maximum memory | 128 GB |
| Processor cache | 18432 KB |
| Supported memory types | DDR4-SDRAM, DDR3-SDRAM |
| Product type | System on Chip |
| Weight & dimensions | |
|---|---|
| Processor package size | 37.5mm x 37.5mm |
| Other features | |
|---|---|
| Maximum internal memory | 128 GB |
