Lenovo 7N47A00081 internal solid state drive 375 GB U.2 PCI Express 3.0 NVMe
- 375 GB U.2 PCI Express 3.0
- 550000 IOPS
- 550000 IOPS
- NVMe
- Component for: Server/workstation
The ThinkSystem U.2 Intel Optane P4800X Performance NVMe PCIe SSD is the ultimate in high performance solid state drives with ultra-low latency, very high bandwidth, and an endurance of up to 60 drive writes per day, making this drive an excellent choice for write-intensive high-performance workloads.
This product guide introduces the P4800X drives and describes their features and specifications, and provides compatibility information. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the drives and consider their use in IT solutions.
| Features | |
|---|---|
| Certification | FCC Title 47, Part 15B, Class BCA/CSA-CEI/IEC CISPR 22:02EN 55024: 1998EN 55022: 2006EN-60950-1 2nd EditionUL/CSA EN-60950-1 2nd EditionLow Voltage Directive 2006/95/ECC-Tick: AS/NZS3584BSMI: CNS 13438KCC Article 11.1RoHS DIRECTIVE 2011/65/EUWEEE Directive 2002/96/EC |
| Mean time between failures (MTBF) | 2000000 h |
| Hot-swap | Yes |
| Write latency | 11 µs |
| Read latency | 10 µs |
| Random write (4KB) | 550000 IOPS |
| Random read (4KB) | 550000 IOPS |
| Component for | Server/workstation |
| NVMe | Yes |
| Interface | PCI Express 3.0 |
| SSD form factor | U.2 |
| SSD capacity | 375 GB |
| Power | |
|---|---|
| Average power consumption (read) | 8 W |
| Average power consumption (write) | 13 W |
| Weight & dimensions | |
|---|---|
| Height | 15 mm |
| Depth | 100 mm |
| Width | 70 mm |
| Operational conditions | |
|---|---|
| Maximum operating altitude | 3048 m |
| Operating shock | 1000 G |
| Operating relative humidity (H-H) | 5 – 95% |
| Operating temperature (T-T) | 0 – 35 °C |
