Lenovo S4500 960 GB 2.5″ Serial ATA III 3D TLC
- 960 GB 2.5″ Serial ATA III
- Read speed: 500 MB/s
- Write speed: 490 MB/s
- 3D TLC
- Hardware encryption 256-bit AES
- S.M.A.R.T. support
- Component for: Server/workstation
The Intel S4500 Entry SATA solid-state drives (SSDs) for Lenovo servers use Intel 3D NAND TLC Flash Memory technology with a 6Gbps SATA interface to provide an affordable solution with industry leading performance. Compared with the Intel S3520 series, these new drives offer improved performance and lower latency. The S4500 SSDs are optimized for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.
| Features | |
|---|---|
| Mean time between failures (MTBF) | 2000000 h |
| Hot-swap | Yes |
| S.M.A.R.T. support | Yes |
| RAID support | Yes |
| Write latency | 36 µs |
| Read latency | 36 µs |
| Maximum write (4KB) | 30000 IOPS |
| Maximum read (4KB) | 72000 IOPS |
| Write speed | 490 MB/s |
| Read speed | 500 MB/s |
| Data transfer rate | 6 Gbit/s |
| Security algorithms | 256-bit AES |
| Hardware encryption | Yes |
| Component for | Server/workstation |
| Memory type | 3D TLC |
| Interface | Serial ATA III |
| SSD form factor | 2.5″ |
| SSD capacity | 960 GB |
| Power | |
|---|---|
| Power consumption (write) | 4.8 W |
| Weight & dimensions | |
|---|---|
| Weight | 63 g |
| Operational conditions | |
|---|---|
| Operating shock | 1000 G |
| Non-operating vibration | 3.13 G |
| Operating vibration | 2.17 G |
| Other features | |
|---|---|
| Product colour | Aluminium |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84717070 |
