Lian Li Uni Fan UF-AL120V2-3W computer cooling system Computer case 12 cm White 3 pc(s)
- Improved daisy chain design to connect 2 clusters of fans
- AL120 V2 fan frame thickness is 28mm to provide 20% improved airflow compared to V1
- Removable interlocking keys to provide better radiator clearance
- Start/stop fan RPM support for a quieter environment
- New corner lighting visible from all sides
- Only one cable is required for each fan cluster when using the provided new UNI HUB to control lighting effects via L-Connect 3
UPGRADED MODULARITY
UNI FAN AL V2 features an interlocking system to connect up to 6 fans in two clusters to a single controller port, making fans installation and cable management a simple job.
THICKER YET EASY TO INSTALL
The UNI FAN AL120 V2 has been amended to a slightly thicker frame of 28mm, and implements indented screw holes to fit standard 25mm long screws for installation.
ULTIMATE PERFORMANCE ARGB FAN
Running at peak performance while keeping low noise levels, the UNI FAN AL120 V2 is the best-performing ARGB fan within the entire UNI FAN lineup.
DAZZLING FROM ALL ANGLES
UNI FAN ALV2 has comprehensive lighting all around with independent control of the effects at the fan blades and fan frame, and combined lighting effects.
MORE LIGHTING EFFECT CHOICES
New lighting effects have been developed for the updated version of the AL fans, offering more lighting options.
CONTINUOUS LIGHTING EFFECTS
A merge function is available to allow lighting effects to flow not only across a single cluster but across the whole system.
L-CONNECT 3 SOFTWARE TO CONTROL AL-V2 FANS
Control and preview with precision the lighting effect of the AL-V2 fans with the new L-Connect interface.
| Performance | |
|---|---|
| Quantity per pack | 3 pc(s) |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Maximum air pressure | 2.97 mmH2O |
| Maximum airflow | 77.3 cfm |
| Noise level (high speed) | 28.7 dB |
| Rotational speed (max) | 2000 RPM |
| Rotational speed (min) | 250 RPM |
| Fan diameter | 12 cm |
| Type | Fan |
| Suitable location | Computer case |
| Design | |
|---|---|
| Illumination colour | Multi |
| Illumination LED | Yes |
| Material | Aluminium, Polybutylene terephthalate (PBT), Polycarbonate (PC) |
| Product colour | White |
| Power | |
|---|---|
| LED voltage | 5 V |
| VRM fan power consumption | 7.2 W |
| Starting voltage | 5 V |
| Rated voltage | 12 V |
| Weight & dimensions | |
|---|---|
| Fan thickness | 2.8 cm |
| Fan dimensions (W x D x H) | 120 x 120 x 28 mm |
| General | |
|---|---|
| Product family | Uni Fan |
| Packaging content | |
|---|---|
| Package type | Box |
