NETGEAR ReadyNAS 4220 Rack (2U) Intel® Xeon® E3 Family E3-1225 8 GB DDR3 18 TB Black, Silver
- Rack (2U) Black, Silver
- Total installed storage capacity: 18 TB Number of storage drives supported: 12
- Intel® Xeon® E3 Family E3-1225 3.1 GHz Intel® HD Graphics P3000
- 8 DDR3
- Ethernet LAN Jumbo frames support iSCSI support
- 550 W
– 12-bay 2U unified (NAS/SAN) storage (48TB max. capacity).
– All ReadyNAS 4220 include 2x10GbE ports (10GBase-T, except for RN4220S which features 2xSFP+).
– Consolidate, backup and share files across Windows, Mac, Linux, iOS and Android devices.
– On-box data protection including XRAID automatic volume expansion, unlimited snapshots, encryption and real-time anti-virus.
– Modern interface for easy cloud-based discovery and file management.
– VM-ready with iSCSI support and vSphere™/Hyper-V™ certification.
Application data, virtual images, client files, email… the types of data central to running a successful business can seem endless. With ReadyNAS you finally have an advanced and easy-to use solution for centralizing, securing and controlling access to your digital assets. Way more than just simple unified (NAS and SAN) storage for your company, ReadyNAS allows you to do more than you ever thought you could afford by pairing the latest in performance with innovative efficiency technologies such as unlimited snapshots, thin provisioning and cloud-managed replication.
Every networked attached storage (NAS) device from NETGEAR runs on the revolutionary ReadyNAS operating system. This custom-built OS protects stored data with XRAID2 automatic expansion and offers continuous data protection with unlimited snapshots. 2×10 GbE, real-time anti-virus and native encryption come standard on all models.
Designed specifically for the unique needs of business users, ReadyNAS devices utilize proprietary ReadyCLOUD™ technology for cloud-based discovery, provisioning and ongoing management. In addition, these devices are virtualization-ready with iSCSI support, thin provisioning capability and certification with VMware and Microsoft.
These days, your data is your world. With ReadyNAS, protecting and accessing that world has never been easier. ReadyNAS — Storage Made EASY.
| Storage | |
|---|---|
| Supported file systems | ext3, ext4, FAT32, HFS+, NTFS |
| Hot-swap drive bays | Yes |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| RAID support | Yes |
| Maximum supported storage capacity | 48 TB |
| Storage drive size | 2.5/3.5″ |
| Storage drive interface | Serial ATA |
| Storage drive capacity | 3 TB |
| Number of storage drives supported | 12 |
| Number of storage drives installed | 6 |
| Total installed storage capacity | 18 TB |
| Processor | |
|---|---|
| Memory bandwidth supported by processor (max) | 21 GB/s |
| Maximum internal memory supported by processor | 32 GB |
| On-board graphics card model | Intel® HD Graphics P3000 |
| CPU configuration (max) | 1 |
| Processor codename | Sandy Bridge |
| Tcase | 72.6 °C |
| Number of processors installed | 1 |
| CPU multiplier (bus/core ratio) | 31 |
| Bus type | DMI |
| System bus rate | 5 GT/s |
| ECC supported by processor | Yes |
| PCI Express slots version | 2.0 |
| Processor cache type | Smart Cache |
| Processor code | SR00G |
| Processor lithography | 32 nm |
| Processor operating modes | 64-bit |
| Processor package size | 37.5 x 37.5 mm |
| Processor socket | LGA 1155 (Socket H2) |
| Stepping | D2 |
| Thermal Design Power (TDP) | 95 W |
| Processor cache | 6 MB |
| Processor threads | 4 |
| Processor cores | 4 |
| Processor boost frequency | 3.4 GHz |
| Processor frequency | 3.1 GHz |
| Processor model | E3-1225 |
| Processor family | Intel® Xeon® E3 Family |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Flash memory | 256 MB |
| Internal memory type | DDR3 |
| Internal memory | 8 GB |
| Network | |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| iSCSI support | Yes |
| Jumbo frames support | Yes |
| DHCP client | Yes |
| Wi-Fi | No |
| Ethernet LAN data rates | 10,100,1000,10000 Mbit/s |
| Ethernet LAN | Yes |
| Ports & interfaces | |
|---|---|
| eSATA | Yes |
| eSATA ports quantity | 2 |
| Fiber ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| Graphics | |
|---|---|
| Number of displays supported (on-board graphics) | 2 |
| On-board graphics card base frequency | 850 MHz |
| On-board graphics card dynamic frequency (max) | 1350 MHz |
| Design | |
|---|---|
| LED indicators | Yes |
| Number of fans | 3 fan(s) |
| Product colour | Black, Silver |
| Chassis type | Rack (2U) |
| Performance | |
|---|---|
| Security algorithms | 256-bit AES |
| On/off switch | Yes |
| Access Control List (ACL) | Yes |
| Web-based management | Yes |
| Noise level | 30 dB |
| Number of users | 8192 user(s) |
| Software | |
|---|---|
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Windows operating systems supported | Yes |
| Power | |
|---|---|
| AC input frequency | 50 – 60 Hz |
| AC input voltage | 100-240 V |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| Power supply unit (PSU) capacity | 550 W |
| Weight & dimensions | |
|---|---|
| Weight | 1.2 kg |
| Height | 88 mm |
| Depth | 707 mm |
| Width | 445 mm |
| Processor special features | |
|---|---|
| Memory types supported by processor | DDR3-SDRAM |
| Memory channels supported by processor | Dual |
| Embedded options available | Yes |
| Execute Disable Bit | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | 2.0 |
| Maximum number of PCI Express lanes | 20 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Demand Based Switching | Yes |
| Intel Dual Display Capable Technology | Yes |
| Intel Fast Memory Access | Yes |
| Intel FDI Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Idle States | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Smart Cache | Yes |
| Intel® Wireless Display (Intel® WiDi) | No |
| Thermal Monitoring Technologies | Yes |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 20 – 80% |
| Operating temperature (T-T) | 0 – 40 °C |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84714100 |
| Other features | |
|---|---|
| Processor ARK ID | 52270 |
| Certification | FCC A, CE A, VCCI A |
| Compliance certificates | RoHS |
