Opengear CM8116-UK console server RS-232
- 16, 32 or 48 port serial console server with Smart Out-of-Band™
- Enables Data Center and Enterprise Network automation with Python and Docker support
- Ideal replacement for legacy terminal servers
- Embedded physical security using TPM 2.0 module
- Dual power supplies with independent monitoring
- Integrated environmental temperature monitoring
CM8100 Console Server
The CM8100 is Opengear’s newest console manager for data centers and enterprise networks. Building on 18 years of Opengear product innovation and leadership, the CM8100 Console Manager provides up to 48 serial ports, enterprise-grade security using TPM 2.0 module, and independent monitoring using dual power supplies.
Connect 16, 32, or 48 serial console ports with simple straight-through cabling to Cisco®-style serial consoles reliably regardless of the state of your production network.
Host containerized applications to run across any platform or NetOps tools providing more agility and efficiency. Maximize your connectivity and keep data free from slowdowns with Dual Ethernet ports. Manage at scale through Opengear’s Lighthouse Management Software.
Designed and purpose-built energy efficient without compromising performance, the CM8100 requires less power and cooling for a lower total cost of ownership and high reliability.
| Technical details |
| Rack mounting |
Yes |
| Zero Touch Provisioning (ZTP) |
Yes |
| Web-based management |
Yes |
| Supported programming languages |
Perl, Python |
| Compliance certificates |
RoHS |
| Temperature sensor |
Yes |
| Product colour |
Black, Red |
| MIB support |
Yes |
| Security |
| Security algorithms |
IPSec, SNMP, SSH |
| Authentication method |
TACACS+, RADIUS, OpenLDAP |
| Processor |
| Processor frequency |
1600 MHz |
| Processor cores |
2 |
| Processor architecture |
ARM Cortex-A9 |
| Processor model |
88F6820 |
| Processor family |
Marvel |
| Operational conditions |
| Operating temperature (T-T) |
5 – 50 °C |
| Operating relative humidity (H-H) |
5 – 90% |
| Power |
| Number of power supply units |
2 |
| Power consumption (typical) |
15 W |
| AC input voltage |
100 – 240 V |
| Network |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-T, 1000BASE-T |
| Memory |
| Flash memory |
32000 MB |
| RAM type |
DDR4 |
| Internal memory |
2000 MB |
