Phanteks Evolv X2 Midi Tower Black
- Midi Tower PC Gaming
- ATX, EATX, micro ATX, Mini-ITX
- Supported HDD sizes: 2.5,3.5″ SSD form factor: 2.5″
- Number of 2.5″ bays: 5 Number of 3.5″ bays: 2
- Side window Illumination Multi Tempered glass panel(s)
- Acrylonitrile butadiene styrene (ABS), Aluminium, Steel, Tempered glass
- Black
Redefine the desktop computer
The Evolv X2 redefines the desktop computer with its see-through glass design, aluminum interior, and powerful vertical cooling solution. The entire chassis floats above its base, drawing in surrounding air and channeling it efficiently through the GPU and CPU. Hot air is expelled through the top ventilation, enhancing thermal performance.
The interior of the Evolv X2 has been carefully designed to blend with the hardware components for a fully integrated look, with all cooling components sitting flush into the top and base. The integrated lighting and high-quality aluminum internal panels add flair to your system.
Designed To Cool
Efficient vertical airflow design, drawing fresh air from the bottom and expelling warm air through the top.
Floating chassis design ensures superior cooling by maximizing air intake through the bottom fan positions.
Hot air is exhausted through the top, directed away from the user, thanks to the slanted grill design.
Looking Clean
Mainboard and graphics card sitting front and center.
Cooling fans and radiator sit hidden into the chassis as one.
The large cover door fully hides all cables behind the mainboard.
Supports rear-connect mainboards for a zero-cable build.
Premium Build Quality
Super strong steel and aluminum C-frame design.
Unique see-through chassis showcases the mainboard and graphics card.
Brushed aluminum interior wrapped around the cooling components.
| Design | |
|---|---|
| Maximum PSU length | 25 cm |
| Maximum graphics card length | 38 cm |
| Maximum CPU cooler height | 17 cm |
| On/off button | Yes |
| Reset button | Yes |
| Heat sink included | Yes |
| Tempered glass panel(s) | Yes |
| Illumination colour | Multi |
| Illumination | Yes |
| Suitable for | Gaming |
| Side window | Yes |
| Number of expansion slots | 8 |
| Number of 2.5″ bays | 5 |
| Number of 3.5″ bays | 2 |
| Supported motherboard form factors | ATX, EATX, micro ATX, Mini-ITX |
| Product colour | Black |
| Material | Acrylonitrile butadiene styrene (ABS), Aluminium, Steel, Tempered glass |
| Type | PC |
| Form factor | Midi Tower |
| Power supply | |
|---|---|
| Number of power supply units | 1 |
| Power supply location | Bottom |
| Ports & interfaces | |
|---|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 2×2 Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Cooling | |
|---|---|
| Top radiator sizes supported | 360 mm |
| Suitable location | Computer case |
| Bottom fans installed | 3x 120 mm |
| Top fans diameters supported | 120,140 mm |
| Number of top fans supported (max) | 3 |
| Top fans installed | 3x 120 mm |
| Rear fans diameters supported | 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans installed | 1x 120 mm |
| Storage | |
|---|---|
| SSD form factor | 2.5″ |
| Supported HDD sizes | 2.5,3.5″ |
| Packaging content | |
|---|---|
| Manual | Yes |
| Weight & dimensions | |
|---|---|
| Radiator height | 3.2 cm |
| Radiator depth | 41.5 cm |
| Radiator width | 13 cm |
| Weight | 14.2 kg |
| Height | 588 mm |
| Depth | 288 mm |
| Width | 454 mm |
| Other features | |
|---|---|
| Screws included | Yes |
