Plustek OpticFilm 135i Film/slide scanner 7200 x 7200 DPI Black, Silver
- Scanner type: Film/slide scanner 7200 x 7200 DPI
- Maximum scan size: 35 x 226 mm Sensor type: CCD
- USB port
- Power supply type: DC
Automatic Batch Scanning
It can scan four slides and 6 image frames of one film strip at once.
Brilliant image quality
The OpticFim 135i offers the well-known and striking image quality of Plustek film scanner product series. Its well-designed optical system brings better picture quality, greater light sensitivity, and lower image noise.
7200 dpi Resolution
The optical resolution is tested and ensured by USAF 1951. Plustek OpticFilm 135i scanning resolution ranges from 600 dpi to 7200 dpi. With the maximum 7200 dpi optical resolution, an output of up to 69.2 megapixel images (10224px * 6748px) and more.
48 bit Color Depth
More smooth colors to work with for further image processing
Built-in Infrared Channel
Detecting the dust and scratches on the film source image
| Scanning | |
|---|---|
| Black/white scanning colour modes | Grayscale, Monochrome |
| Film scanning | Yes |
| Output greyscale depth | 8 bit |
| Output colour depth | 24 bit |
| Input greyscale depth | 16 bit |
| Input colour depth | 48 bit |
| Duplex scanning | No |
| Optical scanning resolution | 7200 x 7200 DPI |
| Maximum scan size | 35 x 226 mm |
| Design | |
|---|---|
| Product colour | Black, Silver |
| Built-in display | No |
| Scanner type | Film/slide scanner |
| Performance | |
|---|---|
| High Dynamic Range (HDR) supported | Yes |
| Button functions | Scan |
| Light source | LED |
| Sensor type | CCD |
| Paper handling | |
|---|---|
| Maximum scan length | 22.6 cm |
| Maximum scan width | 3.5 cm |
| Ports & interfaces | |
|---|---|
| Standard interfaces | USB 2.0 |
| USB version | 2.0 |
| USB port | Yes |
| Power | |
|---|---|
| Current | 0.75 A |
| Input voltage | 24 V |
| Power supply type | DC |
| Weight & dimensions | |
|---|---|
| Weight | 1.56 kg |
| Height | 104.3 mm |
| Depth | 175 mm |
| Width | 259.2 mm |
| Packaging data | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Packaging content | |
|---|---|
| Bundled software | Plustek QuickScan Plus |
| General | |
|---|---|
| Product family | OpticFilm |
| System requirements | |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 |
| Minimum storage drive space | 20000 MB |
| Minimum RAM | 4000 MB |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
