StarTech.com PCI Express AC1200 Dual Band Wireless-AC Network Adapter – PCIe 802.11ac WiFi Card
- Wireless
- PCI Express Ethernet / WLAN
- 867 Mbit/s
- Wi-Fi Dual-band (2.4 GHz / 5 GHz)
- Internal Chipset: RTL8812AE
Add high speed 802.11ac WiFi connectivity to a desktop PC through a PCI Express slot with dual band 2.4/5 GHz frequencies and up to 867Mbps
The PEX867WAC22 PCI Express AC1200 Wireless Network Adapter lets you add dual-band Wireless-AC connectivity to a desktop computer through a PCIe slot.
With increased demand on network resources, this Wireless-AC adapter gives you exceptional speed and range for your office or home wireless network when paired with an 802.11ac router. This dual-band WiFi adapter supports maximum data rates of up to 867 Mbps on the 5GHz band (3x the speed of Wireless-N), plus up to 300 Mbps on the 2.4GHz band, making it the perfect solution for applications like HD video streaming, online conferencing, file transfers and gaming.
This versatile PCIe wireless card features a 2T2R (2 transmitter, 2 receiver) detachable antenna design, with an included magnetic antenna stand that can easily be mounted to the top or side of your PC case. Plus, the controller card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers. To integrate with all of your networking devices, the adapter is also backward compatible with 802.11a/b/g/n networks.
Backed by a StarTech.com 2-year warranty, with free lifetime technical support.
The StarTech.com Advantage
– Experience faster wireless speed and better coverage with 802.11ac compatibility
– Ensure fast and dependable wireless networking, with less interference through dual band 2.4 GHz / 5 GHz operation
– Connect to existing wireless networks with 802.11a/b/g/n backward compatibility
Ports & interfaces | |
---|---|
Interface | Ethernet / WLAN |
Host interface | PCI Express |
Connectivity technology | Wireless |
Network | |
---|---|
Full duplex | Yes |
Security algorithms | 128-bit WEP, 64-bit WEP, TKIP, WEP, WPA, WPA2 |
WLAN data transfer rates supported | 300,867 Mbit/s |
Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Frequency range | 2.4 – 5 GHz |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
Wi-Fi | Yes |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Maximum data transfer rate | 867 Mbit/s |
Design | |
---|---|
LED indicators | Activity, Link |
Chipset | RTL8812AE |
Antenna connector type | RP-SMA |
Antenna | Yes |
Product colour | Green |
Internal | Yes |
System requirements | |
---|---|
Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
Weight & dimensions | |
---|---|
Weight | 370 g |
Height | 18 mm |
Depth | 120 mm |
Width | 83 mm |
Packaging data | |
---|---|
Package weight | 388 g |
Package height | 59 mm |
Package depth | 210 mm |
Package width | 156 mm |
Packaging content | |
---|---|
Manual | Yes |
Technical details | |
---|---|
Compliance certificates | RoHS |
Logistics data | |
---|---|
Harmonized System (HS) code | 85176990 |
Other features | |
---|---|
Detachable antenna(s) | Yes |
Gain | 5 dBi |
