Transcend JetRam Speicher 4GB memory module 1 x 4 GB DDR3 1600 MHz
- Laptop 4 GB DDR3 1600 MHz
- 204-pin SO-DIMM 1 x 4 GB
- CAS latency: 11
- 1.5 V
The JM1600KSN-4G is a 512M x 64bits DDR3-1600 SO-DIMM. The JM1600KSN-4G consists of 16pcs
256Mx8bits DDR3 SDRAMs FBGA packages and a 2048 bits serial EEPROM on a 204-pin printed circuit board.
The JM1600KSN-4G is a Dual In-Line Memory Module and is intended for mounting into 204-pin edge connector sockets. Synchronous design allows precise cycle control with the use of system clock. Data I/O transactions are possible on both edges of DQS. Range of operation frequencies, programmable latencies allow the same device to be useful for a variety of high bandwidth, high performance memory system applications.
| Features |
| Certification |
RoHS |
| Module configuration |
512M x 64 |
| Memory voltage |
1.5 V |
| CAS latency |
11 |
| Memory form factor |
204-pin SO-DIMM |
| Component for |
Laptop |
| Memory clock speed |
1600 MHz |
| Internal memory type |
DDR3 |
| Memory layout (modules x size) |
1 x 4 GB |
| Internal memory |
4 GB |
| General |
| Product family |
JetRam |
| Weight & dimensions |
| Height |
1 mm |
| Depth |
30 mm |
| Width |
67.6 mm |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
| Other features |
| Chips organisation |
256Mx8 |
