Transcend MTE652T2 128 GB M.2 PCI Express 3.1 NVMe 3D TLC NAND
- DRAM Cache embedded
- 30µ” PCB gold finger
- Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
- PCIe Gen 3 x4 interface
- Key components fortified by default with Corner Bond technology
- Compliant with PCI Express specification 3.1
- Compliant with NVM Express specification 1.3
- Supports NVM command
- SLC caching technology
- Built-in LDPC ECC (Error Correction Code) functionality
- Dynamic thermal throttling
- Compliant with RoHS 2.0 standards
- Supports Transcend SSD Scope Pro software
Transcend’s MTE652T2 M.2 SSD features the PCI Express (PCIe) Gen 3 x4 interface and is compatible with NVM Express (NVMe) 1.3 specifications, delivering unparalleled transfer speeds. The MTE652T2 features the latest 3D NAND technology for higher storage efficiency, 30µ” PCB gold finger and Corner Bond technology for enhanced durability, built-in DRAM cache for fast access, an extended operating temperature range from -20°C to 75°C, and an endurance rating of 3K Program/Erase cycles for reliable operation.
| Features |
| Certification |
CE/FCC/BSMI |
| Mean time between failures (MTBF) |
3000000 h |
| ECC |
Yes |
| Sequential write speed (CDM) |
1000 MB/s |
| Sequential read speed (CDM) |
2100 MB/s |
| Random write (4KB) |
235000 IOPS |
| Random read (4KB) |
165000 IOPS |
| Component for |
PC/Laptop |
| Memory type |
3D TLC NAND |
| NVMe version |
1.3 |
| NVMe |
Yes |
| Interface |
PCI Express 3.1 |
| SSD form factor |
M.2 |
| SSD capacity |
128 GB |
| Power |
| Power consumption (sleep) |
0.6 W |
| Power consumption (write) |
3.3 W |
| Power consumption (read) |
3.3 W |
| Operating voltage |
3.3 V |
| Weight & dimensions |
| Weight |
9 g |
| Height |
3.58 mm |
| Depth |
22 mm |
| Width |
80 mm |
| Operational conditions |
| Operating shock |
1500 G |
| Operating vibration |
20 G |
| Operating relative humidity (H-H) |
5 – 95% |
| Storage temperature (T-T) |
-40 – 85 °C |
| Operating temperature (T-T) |
-20 – 75 °C |
| Other features |
| Compliance certificates |
RoHS |
