Transcend SATA III M.2 SSDs 128 GB Serial ATA III 3D NAND
- Dynamic thermal throttling
- Built-in LDPC ECC (Error Correction Code) functionality
- Advanced Garbage Collection
- Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
- TRIM command for better performance
- NCQ command for better performance
- Power-saving DevSleep (Device Sleep) mode
Transcend’s MTS952P M.2 SSD features the SATA III 6Gb/s interface, delivering superior transfer speeds. The MTS952P features the latest 3D NAND technology for high storage efficiency, 30µ” PCB gold finger and Corner Bond technology for enhanced durability, built-in DRAM cache for fast access, an extended operating temperature range from -20°C to 75°C, and an endurance rating of 3K Program/Erase cycles for reliable operation. The built-in Power Loss Protection (PLP) further ensures data integrity in mission-critical applications.
Transcend also offers the MTS952P-I with wide temperature (-40℃ ~ 85℃) capabilities to ensure sustained functionality, enhanced endurance and optimal reliability in mission-critical applications.
| Features |
| TBW rating |
1760 |
| Mean time between failures (MTBF) |
3000000 h |
| Drive writes per day (DWPD) |
1.61 |
| Sequential write speed (CDM) |
520 MB/s |
| Sequential read speed (CDM) |
560 MB/s |
| Random write (4KB) |
85000 IOPS |
| Random read (4KB) |
95000 IOPS |
| Data transfer rate |
6 Gbit/s |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Hardware encryption |
Yes |
| Component for |
Universal |
| Memory type |
3D NAND |
| NVMe |
No |
| Interface |
Serial ATA III |
| SSD form factor |
M.2 |
| SSD capacity |
128 GB |
| Power |
| Power consumption (sleep) |
0.4 W |
| Power consumption (read) |
2.3 W |
| Operating voltage |
3.3 V |
| Weight & dimensions |
| Weight |
9 g |
| Height |
3.88 mm |
| Depth |
22 mm |
| Width |
80 mm |
| Operational conditions |
| Vibration resistance |
20 G |
| Operating shock |
1500 G |
| Operating relative humidity (H-H) |
5 – 95% |
| Storage temperature (T-T) |
-55 – 85 °C |
| Operating temperature (T-T) |
-20 – 75 °C |
