Ubiquiti UCG-Fiber (30W) gateway/controller 10, 100, 1000, 2500, 10000 Mbit/s
- 10,100,1000,2500,10000 Mbit/s
- Control display unit Built-in processor 2200 MHz 3000 MB
- Power over Ethernet (PoE) Quality of Service (QoS) support VLAN support
- Enclosure material: Polycarbonate (PC)
- White
Desktop 10G Cloud Gateway with integrated 4-port 2.5 GbE switch, selectable NVR storage, and full UniFi application support.
| Design |
| LED indicators |
Status |
| Enclosure material |
Polycarbonate (PC) |
| Product colour |
White |
| Performance |
| Internal memory |
3000 MB |
| Number of processors installed |
1 |
| Processor frequency |
2200 MHz |
| Processor manufacturer |
ARM |
| Processor family |
ARM Cortex |
| Built-in processor |
Yes |
| Display type |
LCM |
| Control display unit |
Yes |
| Protocols |
| Routing protocols |
OSPF |
| Network |
| Load balancing |
Yes |
| Bluetooth |
Yes |
| Ethernet LAN data rates |
10,100,1000,2500,10000 Mbit/s |
| Security |
| Firewall security |
Yes |
| VLAN support |
Yes |
| Security algorithms |
802.1x RADIUS, IPSec, TLS |
| Ports & interfaces |
| DC-in jack |
Yes |
| SFP+ ports quantity |
2 |
| WAN connection |
Ethernet (RJ-45), SFP |
| Ethernet LAN (RJ-45) ports |
4 |
| Management features |
| Quality of Service (QoS) support |
Yes |
| Multicast support |
Yes |
| Reset button |
Yes |
| Power |
| Electromagnetic (EMP) protection (contact) |
4 kV |
| Electromagnetic (EMP) protection (air) |
8 kV |
| Electromagnetic (EMP) protection |
Yes |
| Power over Ethernet (PoE) |
Yes |
| DC input voltage |
54 V |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Input current |
1.1 A |
| Input voltage |
100 – 240 V |
| Power consumption (max) |
29.4 W |
| Weight & dimensions |
| Weight |
675 g |
| Width |
212.8 mm |
| Depth |
127.6 mm |
| Height |
30 mm |
| Packaging content |
| AC adapter included |
Yes |
| Cables included |
LAN (RJ-45), Power |
| Operational conditions |
| Operating relative humidity (H-H) |
5 – 95% |
| Operating temperature (T-T) |
0 – 40 °C |
| Certificates |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Display |
| Display diagonal |
2.44 cm (0.96″) |
