Zotac ZBOX MAGNUS ONE Intel® Core™ i7 i7-13700H 16 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 4070 Windows 11 Home Mini Tower PC Black
- Faster speeds, lower voltage
- Fast read/write speeds
- Faster transfer speeds with compatible SD cards
- Up to 40Gb/s data bandwidth for faster transfer speeds and fast backups
POWER EVOLVED
THE ALL-NEW MAGNUS ONE WITH GEFORCE RTX 40 SERIES
The ZBOX MAGNUS ONE evolves, packing more firepower than ever. Equipped with the latest generational PC hardware, the all-new MAGNUS ONE brings its A-game, so you can too.
AWARD-WINNING DESIGN
MAGNUS ONE has been globally recognized for its outstanding design and performance.
SMALL FRAME, BIG GAME
As compact as ever with its award-winning 8.3L chassis, the MAGNUS ONE gets a generational leap in power and performance. Whether it is for gaming, streaming, or content creation, this compact beast can stand side-by-side in terms of performance with full-sized desktop PCs.
ZOTAC GAMING GEFORCE RTX™ 40 SERIES
Powered by the ultra-efficient NVIDIA Ada Lovelace architecture, the ZOTAC GAMING GeForce RTX 40 series GPU offer increased power efficiency and new features such as DLSS3 frame generation and 3rd generation Ray Tracing, letting you enjoy your games in all their glory.
13TH GEN PROCESSING POWER
Leverage the power of up to 16 cores and 24 threads. The latest 13th gen Intel® Core™ processor within the MAGNUS ONE handles multitasking without breaking a sweat, and is the choice processor for gaming.
THE FAST LANE
Besides the fast GPU and CPU, the MAGNUS ONE has also been upgraded in other aspects for faster file transfers and multitasking performance.
KILLER NETWORKING
Every millisecond of latency can spell victory or defeat. The MAGNUS ONE comes with an Intel® Killer™ 2.5 Gbps Ethernet port and Killer™ Wi-Fi 6 AX1650, giving you a definitive edge in any competition.
TWO TONES,
BOTH SPECTACULAR
Hardware is not the only thing new. The MAGNUS ONE now also comes in either back or white to match your personal setup.
EXPAND & UPGRADE
The ingenious design of the MAGNUS ONE chassis makes upgrading a breeze. Simply unscrew two thumb screws at the rear and remove the top and side panels to gain full access to the internals to add or upgrade memory and storage.
| Processor | |
|---|---|
| Processor base power | 125 W |
| Maximum turbo power | 253 W |
| Number of processors installed | 1 |
| Processor cache type | Smart Cache |
| Processor cache | 30 MB |
| Efficient-core Max Turbo Frequency | 4.2 GHz |
| Performance-core Max Turbo Frequency | 5.3 GHz |
| Efficient cores | 8 |
| Performance cores | 8 |
| Processor frequency | 2.1 GHz |
| Processor threads | 24 |
| Processor cores | 16 |
| Processor model | i7-13700H |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor family | Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Memory slots | 2x SO-DIMM |
| Internal memory type | DDR5-SDRAM |
| Maximum internal memory | 64 GB |
| Internal memory | 16 GB |
| Storage | |
|---|---|
| Compatible memory cards | SD, SDHC, SDXC |
| Card reader integrated | Yes |
| SSD form factor | M.2 |
| SSD interface | M.2, PCI Express 4.0 |
| SSD capacity | 1 TB |
| Number of SSDs installed | 1 |
| Total SSDs capacity | 1 TB |
| Number of storage drives supported | 3 |
| Number of storage drives installed | 1 |
| Storage media | SSD |
| Optical drive type | No |
| Total storage capacity | 1 TB |
| Graphics | |
|---|---|
| On-board graphics card model | Not available |
| Number of discrete graphics cards | 1 |
| Discrete graphics memory type | GDDR6X |
| Discrete graphics card memory | 12 GB |
| Discrete graphics card model | NVIDIA GeForce RTX 4070 |
| Discrete GPU manufacturer | NVIDIA |
| On-board graphics card | No |
| Discrete graphics card | Yes |
| Network | |
|---|---|
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Antenna type | 2×2 |
| WLAN controller model | Killer Wi-Fi 6 AX1650 |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| WLAN controller manufacturer | Killer |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Ethernet LAN data rates | 1000,2500 Mbit/s |
| Ethernet LAN | Yes |
| Ports & interfaces | |
|---|---|
| Headphone outputs | 1 |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| DisplayPort version | 1.4a |
| DisplayPorts quantity | 3 |
| HDMI version | 1.4/2.1 |
| HDMI ports quantity | 2 |
| Thunderbolt 4 ports quantity | 1 |
| Intel® Thunderbolt 4 | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 7 |
| Design | |
|---|---|
| Product colour | Black |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Number of 2.5″ bays | 1 |
| Placement supported | Vertical |
| Chassis type | Mini Tower |
| Performance | |
|---|---|
| Audio output channels | 8.0 channels |
| Market positioning | Gaming |
| Product type | PC |
| Software | |
|---|---|
| Drivers included | Yes |
| Operating system installed | Windows 11 Home |
| Power | |
|---|---|
| 80 PLUS certification | 80 PLUS Platinum |
| Power supply | 500 W |
| Weight & dimensions | |
|---|---|
| Height | 265.5 mm |
| Depth | 249 mm |
| Width | 126 mm |
| Packaging content | |
|---|---|
| Cables included | Power |
| Display included | No |
| General | |
|---|---|
| Product family | ZBOX |
