Transcend TS32GUSDC10I memory card 32 GB MicroSDHC MLC Class 10
- 32 GB MicroSDHC Class 10 MLC
- 20 MB/s
- Black
Industrial Temp microSDHC10I card
Transcend industrial-grade microSD cards offer greater design flexibility and cost savings. Despite their compact size, the microSD cards have excellent temperature flexibility from -40°C to 85°C. The cards are manufactured with high-quality controller and MLC flash chips, providing excellent shock and vibration resistance and low power consumption that help to bring the performance and reliability advantages of industrial memory cards to small form factor devices.
– RoHS compliant
– Operating Voltage: 2.7 ~ 3.6V
– Operating Temperature: -40℃ to 85℃
– Durability: 10,000 insertion/removal cycles
– Compatible with SD Specification Ver. 3.0
– SD File System Specification Ver. 3.0 compliant
– Supports Speed Class Specification Class 10
– Supports Copy Protection for Recorded Media (CPRM) forSD-Audio
– Form Factor: 11mm x 15mm x 1mm
– Power cycle robustness
– Electrostatic protection (ICE 61000-4-2)
– Waterproof (IPX7)
– MLC NAND solution
| Memory |
| Internal memory type |
MLC |
| Write speed |
17 MB/s |
| Read speed |
20 MB/s |
| Flash memory class |
Class 10 |
| Flash card type |
MicroSDHC |
| Capacity |
32 GB |
| Features |
| Mean time between failures (MTBF) |
1000000 h |
| Product colour |
Black |
| Power |
| Memory voltage |
2.7,3.6 V |
| Operational conditions |
| Vibration resistance |
20 G |
| Operating shock |
600 G |
| Storage relative humidity (H-H) |
0 – 95% |
| Operating relative humidity (H-H) |
0 – 95% |
| Storage temperature (T-T) |
-40 – 85 °C |
| Operating temperature (T-T) |
-40 – 85 °C |
| Weight & dimensions |
| Height |
1 mm |
| Depth |
15 mm |
| Width |
11 mm |
| Packaging data |
| Quantity per pack |
1 pc(s) |
| Logistics data |
| Harmonized System (HS) code |
85235190 |
